Fire rated sliding freezer and cold storage door

Meet the fire rated sliding freezer and cold storage doors by AMP!

Fire rated sliding doors offer the safest solution to the cold storage doors, providing protection from the fire for more than 90 minutes. They are constructed with high technology fireproof materials and they bear CE EN 1634-1 certification, in order to ensure fire safety.

Cart CFC & HCFC FRE Customizable dimensions Safe for food storage Forklift ACILITATES THE HACCP METHOD Motorized pallet jack Pallet Jack Personnel Ready for nstallation CAN BE USED BETWEEN-40 °C / +90 °C NSF

Thermal insulation

Up to 0 °C for chiller and up to -40 °C for freezer


Can be constructed in all dimensions

Color variation

Wide colour range


Certified with ISO 9001: 2015 & CE 89/106 EN13241-1 & NSF/ANSI 51

Fire rated sliding doors description

AMP Fire rated sliding door

Testing according to CE EN 1634-1 European Fire Protection Standard

When carrying out the fire resistance tests of the doors, the fire resistant doors include the entire door system including the shutter, door leaf, frame and all accessories. The installation of the door is also part of this system. The laboratory which carries out the fire resistance tests of the doors is certified for these of tests. Below is the certificate of the results of the fire tests.

Fire rated sliding doors specifications

Door leaf thickness

Door leaf thickness 120mm providing insulation for low temperature freezer and positive temperature chiller doors

Door surface

Galvanized sheet is used with external foodsafe antibacterial plastisol coating (250μm).

Non-flammable materials

Non – flammable materials providing fire endurance up to 60min.


Inside the door high tech materials are combined with non flammable polyurethane according to DIN 4102-1.

Heating Elements

Heating elements are used inside the frame and inside the threshold in freezer door.


Insulated frame with high-tech materials made of Stainless steel 304 (sheet metal thickness 1,5mm).

Autoclose mechanism

In case of fire, the door is automatically closed by autoclose mechanism, fire tested for use on fire protection sliding doors. Damper is used to ensure extra safety.

Stainless steel

Stainless steel 304 sheet metal sliding guide fabrication (sheet metal thickness 2mm). Stainless steel heavy duty external and internal handle. Stainless steel wheels and brackets. Stainless steel sliding rail.

Fire rated sliding doors details

AMP Fire rated sliding door details

Fire rated sliding doors options

AMP Fire rated sliding door options

Stainless Steel Sheet

AMP Fire rated sliding door options

Stainless Steel Sheet with circular design

Fire rated sliding door optional inox implementation

AMP's fire rated sliding inox door is made of German origin INOX 304 sheet metal (plain or circular pattern), which prevents corrosion and rust. It can be disinfected with water, soap or disinfectants without damaging the surface or its appearance. It is installed with a stainless steel corner case, internally reinforced with durable heavy-duty PVC, with a modern German design and high mechanical strength. It is resistant to hard use, chemicals and impacts, so it has a long life without needing much maintenance. It is also easy to clean as it does not catch bacteria, fungus or mold.

AMP inox fre rated sliding door


Μπορείτε να προσαρμόσετε την πόρτα ψυκτικού θαλάμου σύμφωνα με τις ανάγκες σας επιλέγοντας την AMP.  Μπορείτε επίσης να προσθέσετε περισσότερα χαρακτηριστικά στο προϊόν σας επικοινωνώντας με το γραφείο της A. Motors.

Video of fire protection resistance testing

Loading video...



Related Documents
